If your pool is closed, update your IntelliCenter system when you open your pool.

Check Your Current Firmware

Go to your IntelliCenter and from the Home screen, select Settings > Advanced System Configuration > System

arrow down, bottom right corner of screen
system menu item, bottom of screen
bottom menu item, firmware update

Next to System Information, you will see your firmware version on the System screen. If your firmware is 1.047, click Firmware Update and follow the screens under Step 2 and select Firmware 1.064.

Update Your Firmware

Based on your current firmware version, click the applicable instructions below.

Updating to Firmware 1.064 Instructions

You cannot update your system to firmware 1.064 unless your current version is 1.047.

Check the IntelliCenter2 app or control panel for the New Update Available notification.

Select Yes if your current firmware version is 1.047. The screen will change from Installing Firmware to System Rebooting to Complete Installation.

new update available screen
installing firmware
system rebooting to complete installation

Note: If there isn’t a message in the IntelliCenter2 app or at the control panel, please contact Technical Support, and they will walk you through the steps to update your system to firmware 1.047.

Manual Firmware Update (USB):

If you prefer manual installation, you can download the 1.064 file to a USB device and install it onto your panel.

If you choose this installation method, follow the 1.047 instruction process below.

If you receive a notification to update your system to 1.064, but your current firmware version is not 1.047, you will need to manually update your system to 1.047 before receiving the 1.064 notification.

Updating to Firmware 1.047 via USB Instructions

Please follow the USB directions below to update your IntelliCenter manually.

STEP 1:
Click the download button to download firmware version 1.047 to your computer. Copy the file name update-ocp-1-047.pfw (1-064.pfw if you are manually installing firmware 1.064) to a USB flash drive on your computer.

Note: You will need a USB flash drive with at least 20MB of space.

STEP 2:
Insert the USB flash drive with the firmware v.1.047 into the USB port on the IntelliCenter Control Panel.

usb port location

STEP 3:
A USB icon should appear next to the Pentair logo, on the top row of the IntelliCenter screen, indicating that your USB flash drive is recognized.

usb indicator

STEP 4:
From the Home screen, go to Settings > Advanced System Configuration > System > Firmware Update

menu arrow down
menu system
menu firmware update

STEP 6:
Choose Update from USB and select the update file you copied on the USB flash drive.

update from USB button

STEP 7:
Choose update from firmware file Update_OCP_v1.047

The file will begin copying and detecting the file. Then follow and watch these screens to begin the download process.

select 1.047 firmware file
copying files to intellicenter
detecting usb device

STEP 8:
Once the file has been detected, click Ok to begin the firmware installation. Allow for the firmware file to configure with your IntelliCenter.

click ok
loading firmware

STEP 9:
Click Ok once you reach the release notes screens. Next, when the screen prompts you, remove your USB flash drive.

click ok
remove usb to complete process

Verify your IntelliCenter Firmware Update

Verify the firmware update: From the Home screen, tap Settings > Advanced System Configuration > System > Firmware

Once your firmware is 1.047, you can wait 48 hours for the 1.064 notification or repeat the 1.047 install process with the 1.064 file.

menu down arrow
menu system
menu firmware update

Download the IntelliCenter2 App

Once your system firmware is 1.064, uninstall the IntelliCenter app from your smart device and install the IntelliCenter2 app.

To continue receiving IntelliCenter updates, be sure to update your user profile with your first name, last name, and email address.
