IntelliFlo3®​ VSF Pool Pump

Main Content Starts Here

IntelliFlo3®​ VSF Pool Pump

Previous
Next

Energy savings and superior performance, all in a game-changing pump

The IntelliFlo3 Variable Speed and Flow Pool Pump sets the new bar for performance with built-in sensorless flow control for effortless optimum flow, and aids in keeping the pool crystal clear and inviting, no matter what it requires.

  • Proprietary flow technology maintains the pool’s optimum flow.
  • Up to 90%* energy savings. Slower speed and regulated flow save energy.
  • New motor, drive, and hydraulics. Department of Energy (DOE) compliant.
  • Easy control via the Pentair Home app or optional touchscreen.
  • WEF 7.1 THP 3.0
Find out where to purchase online or in a retail location near you.
Where to Buy

Explore IF3 VSF

Key Features

IF3 pump image on water background for IF3 landing page

Maintain optimum flow

Even with a high filter load from a big storm or party, your pump adjusts to pool conditions keeping your pool performing at its best.

Energy Efficient icon on top of pool background with green tube

Give the utility bill a break

The combination of variable speed and sensorless flow saves you up to 90%*

woman on phone next to clear blue pool with Pentair Home app

Put your pool on autopilot

The Pentair Home app gives seamless WiFi or Bluetooth® wireless technology control, so you can monitor the pump or change the flow rate from anywhere. Add the optional built-in automation to control up to two other pool devices.

IF3 pump image on water background for IF3 landing page

Maintain optimum flow

Even with a high filter load from a big storm or party, your pump adjusts to pool conditions keeping your pool performing at its best.

Energy Efficient icon on top of pool background with green tube

Give the utility bill a break

The combination of variable speed and sensorless flow saves you up to 90%*

woman on phone next to clear blue pool with Pentair Home app

Put your pool on autopilot

The Pentair Home app gives seamless WiFi or Bluetooth® wireless technology control, so you can monitor the pump or change the flow rate from anywhere. Add the optional built-in automation to control up to two other pool devices.

0101
Pentair home app in iPhone lockup

It's easy to own a pool when it is connected

With the Pentair Home app, simply adjust speed, flow, temp, heat, and timers from a smart device to avoid the trip to the pool pad.

Our Pentair connected products give you a completely intuitive and connected experience for all your connected Pentair products. From product control to monitoring to real-time alerts, the Pentair Home App delivers convenience and peace of mind.

A pump that knows your pool's flow

The IntelliFlo3 gives you confidence and peace of mind in every swim moment. The power to self-adjust to even the most demanding pool features gives you more time to love all the good things about being a pool owner.

Why flow matters

Variable speed and flow technology provide the ultimate system performance, crystal clear water, and energy savings.

graphic about how flow is everything to the IF3
Learn More

Resources

Brochures
Sell Sheets
Manuals

Specifications

Item #DESCRIPTIONTHPWEFMax Input VoltageFREQUENCYFull Load AmpsPort Size (NPT)Weight (LBS)CERTIFICATIONS
011075IntelliFlo3 VSF 3.0HP37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011076IntelliFlo3 VSF 3.0HP with I/O board37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011077IntelliFlo3 VSF 3.0HP with touchscreen37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011078IntelliFlo3 VSF 3.0HP with touchscreen and I/O board37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011065IntelliFlo3 VSF 1.5HP1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
011066IntelliFlo3 VSF 1.5HP with I/O board1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
011067IntelliFlo3 VSF 1.5HP with touchscreen1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
011068IntelliFlo3 VSF 1.5HP with touchscreen and I/O board1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
356159ZIntelliFlo3 VSF Touchscreen Universal Add On3 & 1.5
356365ZIntelliFlo3 VSF optional universal relay board kit3 & 1.5
Item #DESCRIPTIONTHPWEFMax Input VoltageFREQUENCYFull Load AmpsPort Size (NPT)Weight (LBS)CERTIFICATIONS
011075IntelliFlo3 VSF 3.0HP37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011076IntelliFlo3 VSF 3.0HP with I/O board37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011077IntelliFlo3 VSF 3.0HP with touchscreen37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011078IntelliFlo3 VSF 3.0HP with touchscreen and I/O board37.1208-23050/6012.4-11.22" x 2" or 2.5" x 2.5" or 3" x 3"55UL, NSF
011065IntelliFlo3 VSF 1.5HP1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
011066IntelliFlo3 VSF 1.5HP with I/O board1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
011067IntelliFlo3 VSF 1.5HP with touchscreen1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
011068IntelliFlo3 VSF 1.5HP with touchscreen and I/O board1.59.4115/208-23050/6012/6.4-5.91.5" x 1.5" or 2" x 2"48UL, NSF
356159ZIntelliFlo3 VSF Touchscreen Universal Add On3 & 1.5
356365ZIntelliFlo3 VSF optional universal relay board kit3 & 1.5
Show less

RELATED ARTICLES

Choose the right pool pump for your pool
Read More
Pool Pump Information Guide
Read More
Servicing Variable-speed Pumps for Optimal Performance​
Read More

*Savings based on variable speed pump compared to a single-speed pump running 12 hours per day at an average of $0.16 per kWh In a 20,000-gallon pool. Actual savings may vary based on local utility rates, pool size, pump run time, pump horsepower, pump rpm. plumbing size and length, pump model, service factor and other hydraulic factors. Individual Weighted Energy Factor (WEF) scores and savings may vary by model.
